CSM-8 Compact Audio Mixer with Bluetooth and USB Internal Player and Recorder
CSM-8 Compact Audio Mixer with Bluetooth and USB Internal Player and Recorder
CSM-8 Compact Audio Mixer with Bluetooth and USB Internal Player and Recorder
CSM-8 Compact Audio Mixer with Bluetooth and USB Internal Player and Recorder
CSM-8 Compact Audio Mixer with Bluetooth and USB Internal Player and Recorder

Product Description

Compact format audio mixer with 6 mono input channels and a stereo line input. Each mono channel has a combo XLR/jack input with individually switchable mic/instrument impedance and +48V phantom power for the XLR. Input channels have High/Low EQ and Pan controls and mono channels also have Effects level to vary the amount of internal digital delay effect added for vocals or instruments. An internal player/recorder with backlit display can accept a USB memory stick containing compressed audio files in various formats or alternatively connect to a smart phone via BT wireless link. Output is delivered on a pair of balanced XLR connectors and offers very low noise operation for high quality studio or live performances.

  • Integral USB multi-format audio player
  • BT wireless connectivity
  • Digital delay effect for vocals or instruments
  • Individually switchable +48V phantom power
  • Built in record function
  • Supplied with DC power adaptor
  • GAVSHOP CODE: 170.8732UK
  • GAVSHOP LOC: WIN001

Specification : Common

  • Power supply 5Vdc 1A (adaptor included)
  • Power consumption max. 5W
  • Gain -14 to +40dB
  • EQ: low ±15dB @ 80Hz
  • EQ: high ±15dB @ 12kHz
  • Phantom power +48V individually switchable (XLR inputs only)
  • Input impedance : mic 2k Ohms
  • Input impedance : instrument 1M Ohms
  • Input impedance : line 20k Ohms
  • Audio source Internal USB player/recorder & BT receiver
SPECIFICATIONS:
  • Audio format USB playback mp3, wma, ape, flac / record mp3 (48kHz 128kB/s)
  • Bluetooth version 2.1 + EDR
  • Frequency response 20Hz - 20kHz (±0.5B)
  • THD +N <0.03% @ 1kHz
  • Dynamic range 102dB
  • Crosstalk : stereo 92dB
  • Output Left + Right balanced XLR
  • Output impedance 120 Ohms
  • Max. output level 3Vrms
  • Dimensions: 274 x 165 x 66mm

Specifications

Product Code
AVS01 - 170.873UK - 5015972210185

Delivery & Returns

CSM-8 Compact Audio Mixer with Bluetooth and USB Internal Player and Recorder

Item in Stock

Product Code AVS01 - 170.873UK - 5015972210185

Compact format audio mixer with 6 mono input channels and a stereo line input.
