Fusion 200 Zoom Spot (White Housing) Moving Head LED Lighting

MORE STOCK COMING SOON - RESERVE YOURS NOW!

GAVSHOP ORDER CODE: EQLED054A

GAVSHOP LOC: PLC01

The Fusion 200 Zoom Spot features a single 200W LED and produces stunning light shows with a motorised zoom from 11°- 25°. Offering 7 colours plus open along with a rotating and static gobo wheel each containing 7 gobos plus open, the fixture is ideal for installation and performers alike. Two bi-directional prisms (6 facet circular and 5 facet linear) further bolster the fixtures comprehensive features and a motorised zoom keeps the gobos razor sharp over any distance. PowerCON, DMX in/out and a four button LCD display further enhance the fixture.

FEATURES

- 1 x 200W white LED (7500K)
- Adjustable beam angle: 11°-25°
- 11° - 27,900 Lux @ 2m, 25° - 9,855 Lux @ 2m
- 4.3kHz refresh rate
- Motorised zoom and focus
- 6 facet circular rotating prism plus 5 facet linear rotating prism
- Gobo wheel 1: 7 rotating, replaceable gobos + open
- Gobo wheel 2: 7 static gobos + open
- Colour wheel: 7 colours + open
- DMX channels: 2/14 or 18 selectable
- Auto, sound active, manual control and master/slave modes
- Forward facing show mode
- Pan/tilt auto correction
- 16-Bit pan/tilt positioning
- Pan: 540°, Tilt: 270°
- 0-100% dimming and variable strobe
- Quick release omega clamps included
- Square hole spacing on omega clamp receivers allows for clamps to be mounted in all orientations
- 4 push button menu with 2.6” LCDdisplay
- PowerCON input/output
- 3-Pin XLR input/output
- Fan cooled

SPECIFICATIONS

- Power consumption: 240W
- Power supply: 100~240V, 50/60Hz
- Fuse: F4A 250V
- Dimensions: 450 x 302 x 200mm
- Weight: 12.5kg

DOWNLOADS

EQLED054_EQLED054A_Manual.pdf
